ACEPC CK2 mini barebones PC is a compact PC that uses a box that we have seen and that includes the low-power processor Intel Core i5-7200U, a chip with a power far superior to the Celeron or Pentium that usually mount the miniPC’s and that allows us run serious programs such as editing with complete fluency. A good option for price for those who are looking for something more powerful than usual and that also allows 4k @ 60fps output thanks to its DisplayPort port. Reveal more features on ACEPC CK2 mini barebones PC review.
Main Features – ACEPC CK2 mini barebones PC
7th Generation Intel Core i5-7200U CPU, Quad Core,3.50 GHz, 4M Cache
Low-power desktop platform processor, stable and reliable performance, less delay and lag.
Intel HD Graphic 620 GPU
Better and faster in playing games and watching videos than the previous generation. Meet your requirement for high resolution and give you an enjoyable entertainment experience.
Good Heat Dissipation Performance
Built-in excellent cooling fan ensures efficient and rapid heat dissipation. Energy saving, environmental protection, and low power consumption.
Storage Capacity Expansion
HDD / SSD: Supports M.2 2280, NVME / SATA III and Intel Optane Memory, a full size 2.5 inch SSD ( not included )
RAM: DDR4L – 2133 SO-DIMM slot, max to 16GB, Support 1.2V DDR4L 2133 MHz ( not included )
Rich interface, support multiple devices connection
ACEPC CK2 mini barebones PC review Specs
| General | Brand: ACEPC Model: CK2 Type: Mini PC CPU: Core i5 7200U Core: Quad Core GPU: Intel HD Graphics 620 |
|---|---|
| Media Supported | Decoder Format: H.263,H.264,H.265,HD MPEG4 Video format: 4K,AVI,DAT,ISO,MPEG-1,MPEG-4,MPEG1,MPEG2,MPEG4,MPG,WMV Audio format: AAC,APE,FLAC,MP3,WMA Photo Format: GIF,JPEG,JPG,PNG Support 5.1 Surround Sound Output: Yes |
| Product Details | 5G WiFi: Yes WIFI: 802.11 a/b/g/n/ac, Dual-band WiFi 2.4GHz/5GHz , Dual wireless antenna Bluetooth: Bluetooth4.0 Power Supply: Charge Adapter Interface: DC Power Port,DP,HDMI,Mic,Phone,RJ45,TF card,USB2.0,USB3.0,VGA HDMI Version: 2.0 Other Functions: DLNA,ISO Files,PAL Power Consumption.: 10W RJ45 Port Speed: 1000M |
| Firmware Information | System Bit: 64Bit System Activation: Yes |
| Power Requirement | Power Type: External Power Adapter Mode Power Input Vol: 12V Suggest Input: 12V 3A Power Adapter Input: 100-240V / 50-60Hz |
| Battery Information | Battery Voltage: 3V Battery Current: 250mA Battery Type: CR2032 Button Battery Battery Capacity: 230mAh |
| Dimension and Weight | Product weight: 0.3000 kg Package weight: 0.6800 kg Product size (L x W x H): 14.00 x 14.00 x 4.50 cm / 5.51 x 5.51 x 1.77 inches Package size (L x W x H): 20.50 x 20.50 x 6.00 cm / 8.07 x 8.07 x 2.36 inches |
| Package Contents | Package Contents: 1 x Mini PC, 1 x Power Adapter, 1 x HDMI Cable, 1 x English Manual |
ACEPC CK2 mini barebones PC comparison
| ACEPC CK2,Mini Barebones PC Intel Core i3-7100U | AK2 Mini PC Intel Celeron J3455, | AK1 Mini PC Intel Celeron Apollo Lake J3455 Processor | |
|---|---|---|---|
| RAM Size | 16 GB | 6 GB | 8 GB |
| Graphics Description | integrated | integrated | integrated |
| Operating System | Windows 10 | Windows 10 | Windows 10 |
ACEPC CK2 mini barebones PC review
Design
The design of this ACEPC CK2 Mini PC allows you to place it discreetly on your desk, the living room furniture or even behind the monitor, installed with the stand included in the box. In this way, you will always keep a very careful aesthetic in any corner of your house where you decide to install it.
Processor and memory
ACEPC CK2 includes an Intel Core i5-7200U processor that has two physical cores and four threads running at a speed of 2.5GHz, integrates an Intel HD Graphics 620 GPU with 24EU and its consumption is between 7.5 and 15W TPD. Inside the small box of the miniPC we also have 8GB of DDR4L RAM, expandable up to 16GB and a 128GB SSD although we do not know the type since this miniPC has an interface M.2 on one side and another SATA3 with a bay for discs of 2 ,5″.
Ports and connectivity
This miniPC ACEPC CK2 also includes in the wireless connectivity section Dual Band WiFi and Bluetooth 4.2. The available connectors found in the perimeter of your box are multiple, 4 USB 3.0, 2 USB 2.0, a pair of audio jacks, Gigabit network port and VGA video outputs, HDMI 1.4 and DisplayPort.
